FUJI SC 100 Series Controllers

Fully programmable multi-function PID controller

The SC 100 Series is a fully programmable multi-function PID controller with a highly visible color graphic 4.3“ TFT, 256 colors LCD display. The controller has an intuitive touch panel, advanced computation and sequential control functions.

The SC 100 series is fully compatible in format and functionality with all existing PID controllers in the market, which makes the controller ideal for replacing existing 3x6” older controllers. Control, display and I/O functions are managed by independent CPUs for enhanced security and reliability.

  • Dimension: 72x144 mm (3x6”)
  • Inputs
    • 2 x universal inputs (4-20 mA, VDC, T/C, RTD, Ω)
    • 4 x 1-5 VDC
    • 5 x discrete/pulse
    • 1 x discrete/high speed pulse
  • Outputs
    • 2 x 4-20 mA
    • 2 x 1-5 VDC
    • 5 x relay or photo MOSFET relay contact
    • 1 x RUN relay contact
  • PID control: single loop, cascade, advanced
  • Logic and step sequence
  • 48 function blocks available for arithmetic operations, time functions, signal selection, limit, alarm and other functions
  • Auto-tuning: limit cycle method
  • Cycle time: variable between 50 ms to 3 sec
  • Power: 100-240 VAC, 50/60 Hz or 24 VDC
  • Self-diagnostics functionallity
  • Infrared communication
