FUJI SC 110 Series Controllers

Fully programmable multi-function PID controller

The SC 110 Series is a fully programmable multi-function PID controller with a highly visible color graphic 4.3“ TFT, 256 colors LCD display. The controller has an intuitive touch panel, advanced computation and sequential control functions.

The SC 110 series is fully compatible in format and functionality with all existing PID controllers in the market, which makes the controller ideal for replacing existing 3x6” older controllers. Control, display and I/O functions are managed by independent CPUs for enhanced security and reliability.

In addition, the SC 110 series has a built-in manual loader and a backup controller that takes over in case of failure of the main controller module. The main control module and the backup control module have individual power supplies for increased reliability.

  • Dimension: 72x144 mm (3x6”)
  • Inputs
    • 2 x universal inputs (4-20 mA, VDC, T/C, RTD, Ω)
    • 4 x 1-5 VDC
    • 5 x discrete/pulse
    • 1 x discrete/high speed pulse
  • Outputs
    • 2 x 4-20 mA
    • 2 x 1-5 VDC
    • 5 x relay or photo MOSFET relay contact
    • 1 x RUN relay contact
  • PID control: single loop, cascade, advanced
  • Logic and step sequence
  • 48 function blocks available for arithmetic operations, time functions, signal selection, limit, alarm and other functions
  • Auto-tuning: limit cycle method
  • Cycle time: variable between 50 ms to 3 sec
  • Main and backup control with separate power supply
  • Power: 100-240 VAC, 50/60 Hz or 24 VDC
  • Self-diagnostics functionality
  • Infrared communication
