100 Series Submersible Level Transmitter
Accurately measures level in liquids and transmits a proportional signal
The EDGE•L 100 Series submersible level transmitter accurately measures level in liquids and transmits a proportional 4-20 mA output signal.
Typical applications are level measurements in pump pits, reservoirs, plastic tanks, Parshall flume or in any vessel where it’s not desired to have a process connection at the bottom.
TECHNICAL SPECIFICATIONS
- Pressure ranges from 120 mmH2O up to 200 mH2O (0.3937 to 656.17 ftH2O)
- Accuracy: ±0.1%
- Stability: Better than ±0.08% of URL per year
- Output: 4-20 mA / HART
- Power supply: 9 to 55 VDC
- Kevlar reinforced polyurethane cable with vent tube
- Media temperature up to 80°C (176°F) continuously
- Sensor diameter: 31 mm (1-¼”)
- 30:1 turndown of URL
APPLICATION FLEXIBILITY
- G ½” threaded level probe
- Intrinsically safe according to EEx ia IIC T4
- Lightning protection
- Custom cable length up to 1000m (3280.84 ft)
- BOX100 connection box (see separate data sheet)
- Cable clamp
