600 Series Submersible Level Transmitter
Accurately measures level in liquids and transmits a proportional signal
The EDGE•L 600 Series submersible level transmitter accurately measures level in liquids and transmits a proportional 4-20 mA output signal. Hart and Modbus as standard.
Typical applications are level measurements in pump pits, reservoirs, plastic tanks, Parshall flume or in any vessel where it’s not desired to have a process connection at the bottom.
TECHNICAL SPECIFICATIONS
- Pressure ranges from 35 mmH2O up to 200 mH2O (0.1148 to 656.17 ftH2O)
- Accuracy: ±0.1% (option: 0.075%)
- Stability: Better than ±0.08% of URL per year
- Output: 4-20 mA / Hart / Modbus RS485
- Power supply: 11 to 48 VDC
- Innovative autozero function
- Kevlar reinforced polyurethane cable with vent tube
- Media temperature up to 80°C (176°F) continuously
- Sensor diameter: 31 mm (1-¼”)
- 100:1 turndown of URL
APPLICATION FLEXIBILITY
- G ½” threaded level probe
- Intrinsically safe according EEx ia IIC T4 (Pending)
- Lightning protection
- Custom cable length up to 1000m (3280.84 ft)
- BOX100 connection box (see separate data sheet)
- Cable clamp
- Modbus configuration kit including MEP 7 Modbus PC software, RS485 USB modem, battery supply and connection to low resistance mA meter
