BOX100
Connection Box for Submersible Level Transmitter
The EDGE•L BOX100 is specially designed to be used together with 100 Series, 300 Series and 600 Series submersible level transmitters.
The box is equipped with cable glands and terminals for the connection of the level probe cable and the signal/power supply cable as well as a connection for the probe cable atmospheric vent tube.
TECHNICAL SPECIFICATIONS
- Dimensions: 81 x 126 x 57 mm (3.19 x 4.96 x 2.24 in)
- 2 cable glands for round cable 5-12 mm diameter (0.2-0.47 in)
APPLICATION FLEXIBILITY
- Lightning protection
- LCD display with engineering units
