FKB, FKD & FKM Gauge, Differential and Absolute Pressure Transmitter for Remote Seal(s) with Safety Functions
Exceptional performance in accuracy, long term stability and functionalities
The FCX-AII VG Series FKB, FKD & FKM gauge, differential and absolute pressure transmitters for remote seal(s) with safety functions use the unique and proven silicon sensor with state-of-the-art digital processing to provide exceptional performance in terms of accuracy, long term stability and functionalities. The Advanced Floating Cell design, which protects the pressure sensor against changes in temperature, static pressure and overpressure, substantially reduces total measurement error in actual field applications.
The transmitter with safety functions complies with Safety Integrity Level (SIL) 2 and 3.
TECHNICAL SPECIFICATIONS
- Pressure ranges from 0.32 kPa up to 50000 kPa (0.04641 to 7251.89 psi)
- Accuracy: ±0.065% for differential and gauge pressure models and ±0.2% for absolute pressure models
- Stability: ±0.2% of URL for 10 years
- Output: 4-20 mA / HART rev. 7
- Response time: 80 ms
- SIL2 for hardware and SIL3 for software according to IEC 61508
- Programmable output linearization in up to 14 points
- Burnout current functionality compliant with NAMUR NE43
- Dry calibration without reference pressure
APPLICATION FLEXIBIITY
- Full range of hazardous area approvals
- Built-in RFI filter and lightning arrester
- 6 digits and 5% increment bar graph LCD display with engineering units
- Stainless steel electronic housing
- Wide selection of wetted part materials
