FKP Pressure Transmitter (Direct Mount) with Safety Functions

Exceptional performance in accuracy, long term stability and functionalities

The FCX-AII VG Series FKP pressure transmitter (direct mount) with safety functions uses the unique and proven silicon sensor with state-of-the-art digital processing to provide exceptional performance in terms of accuracy, long term stability and functionalities. The Advanced Floating Cell design, which protects the pressure sensor against changes in temperature, static pressure and overpressure, substantially reduces total measurement error in actual field applications.

The transmitter with safety functions complies with Safety Integrity Level (SIL) 2 and 3.

  • Pressure ranges from 8.125 kPa up to 10000 kPa (1.1784 to 1450.38 psi)
  • Accuracy: ±0.1%
  • Stability: ±0.2% of URL for 10 years
  • Output: 4-20 mA / HART rev. 7
  • Response time: 80 ms
  • SIL2 for hardware and SIL3 for software according to IEC 61508
  • Programmable output linearization in up to 14 points
  • Burnout current functionality compliant with NAMUR NE43
  • Dry calibration without reference pressure
  • Full range of hazardous area approvals
  • Built-in RFI filter and lightning arrester
  • 6 digits and 5% increment bar graph LCD display with engineering units
  • Stainless steel electronic housing
  • Wide selection of wetted part materials
