FKE Level Transmitter

EDF “Not Classified” version for Nuclear Applications.

The FKE level transmitter accurately measures liquid level and transmits a proportional 4-20 mA output signal.

The transmitter uses a unique micro-capacitive silicon sensor in combination with a state-of-the-art digital signal processing to provide exceptional performance in terms of accuracy and stability.

  • Standards: K3/1E
  • Radiation tolerance: 20 krad
  • Abnormally high temperature (LOCA): 85°C (185°F)
  • Seismic: 35G
  • Pressure ranges from 10 mmH2O up to 300000 mmH2O (0.3937 to 11811 inH2O)
  • Accuracy: ±0.17% (option: ±0.1%)
  • Stability: ±0.2% of URL for 3 years
  • Output: 4-20 mA / HART
  • Programmable output linearization in up to 14 points
  • Burnout current functionality compliant with NAMUR NE43
  • Dry calibration without reference pressure
  • Full range of hazardous area approvals
  • Built-in RFI filter and lightning arrester
  • Analog indicator at either the electronics side or terminal side
  • 5 digits LCD display with engineering units
  • Stainless steel electronic housing
  • Wide selection of wetted part materials
