FKG Gauge Pressure Transmitter

EDF “Not Classified” version and EDF “K3A Classified” version for Nuclear Applications.

The FKG gauge pressure transmitter accurately measures pressure and transmits a proportional 4-20 mA output signal.

The transmitter uses a unique micro-capacitive silicon sensor in combination with a state-of-the-art digital signal processing to provide exceptional performance in terms of accuracy and stability.

  • Standards: K3/1E
  • Radiation tolerance: 20 krad
  • Abnormally high temperature (LOCA): 85°C (185°F)
  • Seismic: 35G
  • Pressure ranges from 1.3 kPa up to 50000 kPa (0.18855 to 7251.89 psi)
  • Accuracy: ±0.07%
  • Stability: ±0.1% of URL for 3 years
  • Output: 4-20 mA / HART
  • Programmable output linearization in up to 14 points
  • Burnout current functionality compliant with NAMUR NE43
  • Dry calibration without reference pressure
  • Full range of hazardous area approvals
  • Built-in RFI filter and lightning arrester
  • Analog indicator at either the electronics side or terminal side
  • 5 digits LCD display with engineering units
  • Stainless steel electronic housing
  • Wide selection of wetted part materials
