FYG Analog Gauge Pressure Transmitter
EDF “Not Classified” version and EDF “K3 Classified” version for Nuclear Applications
The FYG analog gauge pressure transmitter accurately measures pressure and transmits a proportional 4-20 mA output signal.
The FYG series is specially designed for safety related applications encountered in nuclear power plants where high reliability and long lifetime under mild to harsh environment are required (radiation with total integrated dose (TID) 50 kGray).
TECHNICAL SPECIFICATIONS
- Standards: K3-ad/1E
- Radiation tolerance: 5 Mrad
- Abnormally high temperature (LOCA): 125°C (257°F)
- Seismic: 35G
- Pressure ranges from 21.7 kPa up to 50000 kPa (3.14732 to 7251.89 psi)
- Accuracy: ±0.25%
- Stability: ±0.2% of URL for 30 days
- Output: 4-20 mA
- Fully analog electronics without any SMART device embedded to ensure the ability to address the highest safety levels in nuclear applications
APPLICATION FLEXIBILITY
- Hazardous area approval according to ATEX
- Built-in RFI filter and lightning arrester
- Stainless steel electronic housing
