FKA Absolute Pressure Transmitter

Accurately measure absolute pressure

The FKA absolute pressure transmitter accurately measures absolute pressure and transmits a proportional 4-20 mA output signal. The transmitter using a unique micro-capacitive silicon sensor in combination with a state-of-the-art digital signal processing to provide exceptional performance in terms of accuracy and stability.

TECHNICAL SPECIFICATIONS
  • Pressure ranges from 1.6 kPa abs up to 10000 kPa abs (0.23206 to 1450,38 psi abs)
  • Accuracy: ±0.2% (option: ±0,1%)
  • Stability: ±0.2% of URL for 10 years
  • Output: 4-20 mA / HART or Foundation Fieldbus
  • Programmable output linearization in up to 14 points
  • Burnout current functionality compliant with NAMUR NE43
  • Dry calibration without reference pressure
Application Flexibility
  • Full range of hazardous area approvals
  • Built-in RFI filter and lightning arrester
  • 5 digits LCD display with engineering units
  • Stainless steel electronic housing
  • Wide selection of wetted part materials
DOCUMENTATION
